Vishay Semiconductors VCAN3xA2-HT5 ESD Protection Diodes

Vishay Semiconductors VCAN3xA2-HT5 ESD Protection Diodes are Bidirectional Symmetrical (BiSy) low capacitance, dual-line ESD protection diodes. The VCAN3xA2-HT5 diodes are AEC-Q101-qualified and engineered for CAN FD Bus applications. The Vishay VCAN3xA2-HT5 ESD protection diodes feature a ±33V or ±36V working range in a DFN1110-3A package.

Features

  • For CAN FD Bus applications
  • Small DFN1110-3A package
  • 2-line ESD protection
  • Working ranges
    • ±33V for VCAN33A2-HT5
    • ±36V for VCAN36A2-HT5
  • Low leakage current IR <0.05μA
  • Low load capacitance CD <6pF (at VR = 5V)
  • AOI capable
  • ESD immunity acc. IEC 61000-4-2
    • ±20kV contact discharge
    • ±20kV air discharge
  • ESD capability according to AEC-Q101, human body model, class H3B >8kV
  • e3 - pins side wall plated with tin (Sn)
  • AEC-Q101 qualified available

Datasheets

Infographic

Infographic - Vishay Semiconductors VCAN3xA2-HT5 ESD Protection Diodes

Application Schematic

Application Circuit Diagram - Vishay Semiconductors VCAN3xA2-HT5 ESD Protection Diodes

PACKAGE DIMENSIONS in millimeters (inches)

Mechanical Drawing - Vishay Semiconductors VCAN3xA2-HT5 ESD Protection Diodes
Publicado: 2023-06-20 | Actualizado: 2023-08-02
